Lexmark CX310dn - 121.XX Fuser Service Check

121.xx Fuser service check
Actions Yes No
Step 1
Turn the printer off, and remove the rear cover. See “Rear cover removal”
on page 221.
Check the cable at JFUSES1 for proper connection to the controller board,
the cable for pinch points, and the cable or connector for any other
damage.
Is the cable damaged?
Replace the fuser
cable.
Go to step 3.
7527
Diagnostic information
83
