Lexmark CX310dn - Right Cover Assembly Removal; Right Scanner Cover Removal

3 Remove the rear scanner cover.
Right cover assembly removal
1 Open the toner supply door.
2 Open the front door.
3 Release the latches (A), and lift off the cover.
Right scanner cover removal
1 Remove the imaging unit in the print engine. See “Imaging unit (IU) removal” on page 266.
2 Raise the scanner assembly to the up position, and lock in place.
7527
Repair information
223
