Lexmark CX310dn - Rear Cover Removal

Rear cover removal
1 Remove the eight screws (A).
2 Swing the side of the cover out, and slide to the right to remove.
3 Remove the rear cover.
Installation note: When installing the rear cover, be sure that the ear (C) is inserted into the bracket (B).
7527
Repair information
221
