Lexmark CX310dn - Diagnostics Menu

When using the ADF:
• Load the document into the ADF tray faceup, short edge
first
• Load up to 50 sheets of plain paper into the ADF tray
• Scan sizes from 105 x 148 mm (4.1 x 5.8 inches) wide to
216 x 355 mm (8.5 x 14 inches) long
• Scan media weights from 14 to 31 lbs
• Do not load postcards, photos, small items,
transparencies, photo paper, or thin media (such as
magazine clippings) into the ADF tray. Place these items
on the scanner glass.
When using the scanner glass:
• Place a document facedown on the scanner glass in the
corner of the green arrow
• Scan or copy documents from 216 x 296.9 mm (8.5 x 11.69
inches) dimension
• Copy books up to 12.7 mm (0.5 inch) thick
Diagnostics menu
• “Entering diagnostics mode” on page 162
• “Available tests” on page 162
• “REGISTRATION” on page 164
• “Skew” on page 166
• “Quick Test” on page 166
• “Alignment Menu” on page 168
• “Scanner calibration” on page 168
• “MISC TESTS” on page 169
• “PRINT TESTS” on page 170
• “Print quality test pages” on page 171
• “HARDWARE TESTS” on page 171
• “DUPLEX TESTS” on page 172
• “INPUT TRAY TESTS” on page 175
• “BASE SENSOR TEST” on page 176
• “DEVICE TESTS” on page 177
• “PRINTER SETUP” on page 177
• “EP SETUP” on page 180
• “TPS Setup: Right or Left” on page 181
• “TPS Setup: Cal Ref Adj” on page 181
• “TPS Setup: Reset Color Cal” on page 181
• “Reports: Menu Settings Page” on page 182
• “EVENT LOG” on page 182
• “Scanner tests” on page 183
• “Exit Diagnostics” on page 188
7527
