200.xx Input (S2) sensor service check
The input (S2) sensor is part of the paper pick motor drive assembly FRU, and is not available otherwise.
Actions Yes No
Step 1
Remove tray 1.
Is the input S2 sensor flag (A) damaged?
Replace the paper pick
motor drive assembly.
See “Paper pick motor
drive assembly
(standard tray)
removal” on page
290.
Go to step 2.
Step 2
Enter Diagnostics Menu.
Turn the printer on, press and hold 3 and 6, and release the buttons with
the installed memory and processor speed displays.
Perform the Base Sensor Test. See “BASE SENSOR TEST” on page 176.
a Select Base Sensor Test, and press Select.
b Select S2 Sensor, and press Select.
c Pull tray 1 out, and rotate the S2 sensor flag (A). (The S2 sensor is
located in the front of the center paper pick motor drive assembly
housing.) It should rotate freely and return to its original position.
7527
Diagnostic information
42
