7 Start button Starts a job, depending on which mode is selected
8 Back button Returns to the previous screen.
9 Home button Goes to the home screen
10 Indicator light Checks the status of the printer
Using the operator panel for CX410 models
Using the operator panel
1 Display
• Views the printer status and messages
• Sets up and operates the printer
2 Home button Goes to the home screen
3 Help button Goes to the Help menus
4 Clear all/Reset button Resets the default settings of a function, such as printing, copying, or e‑mailing
5 Keypad Enters numbers, letters, or symbols
6 Sleep button Enables sleep mode or hibernate mode
7 Cancel button Cancels all printer activity
8 Start button Starts a job, depending on which mode is selected
9 Indicator light Checks the status of the printer
10 USB port Connects a flash drive to the printer
Note: Only the front USB port supports flash drives
7527
Service menus
156
