2 Select the sensor to be tested.
3 Actuate the sensor you selected.
4 The screen will toggle between 0 and 1 if the sensor is properly functioning.
5 Select Exit to leave the test
To test the Paper FB long test, place a sheet of legal paper on the flatbed and close the cover. If the sensor is working
properly, the indicator will change from 0 to 1
To test the Home sensor, perform the following steps:
1 Exit the sensor test.
2 Open the flatbed cover.
3 use the carriage motor test to move the carriage out of home position.
4 Close the flatbed cover.
5 Enter the sensor test. If the home sensor is working properly, then a 1 will display instead of a 0.
Actuator locations
A Stage skew sensor (paper skew)
B Paper present
C Interval sensor
7527
Service menus
186
