Step A: Select the restricted item. In the example shown in “Step A” of Figure 7 the restricted item is
the Auto Single Stroke Time. Once the parameter is selected, if restricted the display will
prompt that an access code is required. The user should press the Access Code key.
Step B: A list of users that have access to this restricted item will appear. In “Step B” of Figure 7, 5 of
the 16 possible users have access to this restricted parameter. The system may have several
more users, but the 5 users listed on the screen are the only users that have access to Auto
Single Stroke time. The user must select his user name (even if there is only one user name
displayed).
Step C: The display will show the selected user name and request the user password as shown in “Step
C” of Figure 7. The user must enter the correct password and then press the Enter key.
Step D: Upon entry of the correct password, the user will be allowed access to the restricted item. In
this example, the user will be allowed to change the Auto Single Stroke Time parameter from
the 10 sec setting that was previously programmed.
10
359
TOP
Stroke
Mode
Continuous
Stroke Speed
0
SPM
ACC
Espanol
Exit
359
TOP
Stroke
Mode
Continuous
Stroke Speed
0
SPM
ACC
Espanol
Exit
Access Code Needed – View Only
Edit
Number
sec
Auto Single
Stroke Time
Access
Code
359
TOP
Stroke
Mode
Continuous
Stroke Speed
0
SPM
ACC
Espanol
Cancel
Select
Setting
No User Selected
Select
User
Select Setting From the List Below
User Number 1
User Number 2
User Number 3
Setup Man Level 1
Setup Man Level 2
359
TOP
Stroke
Mode
Continuous
Stroke Speed
0
SPM
ACC
Espanol
Enter
Edit
Number
Enter Code for User
“User Number 1”
Cancel
9
6
3
8
5
2
7
4
1
0
Clear
Back
359
TOP
Stroke
Mode
Continuous
Stroke Speed
0
SPM
ACC
Espanol
Enter
359
TOP
Stroke
Mode
Continuous
Stroke Speed
0
SPM
ACC
Espanol
Enter
Edit
Number
Cancel
9
6
3
8
5
2
7
4
1
0
Clear
Back
10
sec
Auto Single
Stroke Time
Figure 7: Example Password Entry Sequence
