4.11 Operator Terminal Configuration
The Operator Terminal configuration screen is
accessed by touching the Operator Terminal softkey
in the Main Configuration screen (see Figure 43 on
page 55).
The screen shown in Figure 56 can be used to
configure the operator terminal to display specific
default information in the “top info area” that
appears in all operator screens.
The operator can select any of the “Top Area
Display” items by pressing the top info area, but the
selection made here will be the default at power up.
This screen can also be used to set the real time
clock if necessary.
4.11.1 Top Area Display
The center section of the top display area can be configured to show the following items:
• Part Count
• Current Status
• Reason for Last Stop
• Total Tons
• Cycle Rate
• Press Speed (if using optional 5100-11 encoder)
• Distance to Bottom (if using optional 5100-11 encoder)
The displayed item can change when the stroking mode is changed. The user can chose the item that is
to be displayed in Setup mode and the item that is to be displayed in Production mode.
Note also that touching the “top info area” in any screen will cycle through the available information
items that are not currently shown. This allows the operator to conveniently see any of the items without
having to change them in this screen. The next time the mode is changed, however, the item will be
shown as configured here again.
4.11.2 Rod Length and Stroke Length
The “Rod Length” and “Stroke Length” shown in Figure 56 are used to calculate the distance from the
bottom of the stroke. These items can be displayed and entered in either inches or millimeters.
The “Rod Length” is the length of the connection between the center of the crankshaft and the slide
connection point.
The “Stroke Length” is the total linear travel of the press slide from top to bottom.
