Output Relay Functions
Type Number
Function
Type 0
Not Used (Off)
Type 1
Turn On if Die Protection Bypassed
Type 2
Turn Off if Stroking Inhibited
Type 3
Turn Off if Top Stop
Type 4
Turn Off if Immediate Stop
Type 5
Turn Off if Any Stop
Type 6
Turn Off if Any Stop or Inhibit
Type 7
Turn On if in Setup Mode
Type 8
Turn On if Crank in Motion
Type 9
Turn On if Run/Prog Switch in Prog, Off in Run
Type 10
Turn On if Unit is powered
Type 11
Turn On if LinkNet Down Time Code is Active
