3-55
[15] ADJUSTING OPERATION SEAT
• Adjust the operation seat before operation or when the operator changes.
• Press your back against the back of the operation seat and adjust the seat so that you can fully
step on the acceleration pedal.
[FORWARD/BACKWARD ADJUSTMENT OF THE SEAT]
1. While pushing the slide adjusting lever (1) to the left, set the seat
to the desired position.
2. Release your hand from the slide adjusting lever (1).
NOTES
The forward/backward slide adjustment distance is 120 mm in 6
steps.
[RECLINING ADJUSTMENT]
CAUTION
Watch the space in the back while adjusting the angle when reclining the backseat backward.
1. While pushing the reclining adjusting lever (2) forward, set the backseat to the desired angle.
2. Release your hand from the reclining adjusting lever (2).
NOTES
The reclining adjustment angle is 75 degrees in 7 steps forward and 23 steps in backward.
