6-30
[3] VERIFICATION OF THE LCD SCREEN SIGN AT THE “OUTRIGGER MODE”
1. Push the Power switch to once turn OFF the Transmitter.
2. Push the Power switch again to turn ON the Transmitter.
The “Crane mark” is displayed in the LCD screen for 2 seconds
around.
3. While the “Crane mark” is shown in the LCD screen (for approx. 2 seconds), push the Speed/Mode
button for 2 seconds.
The LCD provides the screen for selecting “CRANE MODE” or “OUTRIGGER MODE”.
4. Use the Hook raising and lowering Lever and shift the cursor ( or ), and push the Setting button
when the cursor points out the “OUTRIGGER”.
Here, confirm that the “Outrigger mark” is exhibited, then it enters into the “Ground setting mode”, soon
after.
To Next Page
