0-5
ITEM
Page
8. OPERATION 6-39
8.1 CAUTIONS BEFORE OPERATION 6-39
8.2 OPERATION IN OUTRIGGER MODE 6-40
8.2.1 OUTRIGGER SETTING 6-41
8.2.2 OUTRIGGER STOWAGE 6-42
8.3 OPERATION IN CRANE MODE 6-43
8.3.1 SLEWING OPERATION 6-44
8.3.2 BOOM TELESCOPING 6-44
8.3.3 HOOK RAISING AND LOWERING 6-45
8.3.4 BOOM DERRICKING 6-45
8.3.5 AUTOMATIC HOOK STOW FUNCTION 6-46
8.3.6 SET-UP AND CANCEL MICRO SPEED AND ENHANCED SPEED MODE 6-47
8.3.7 ENGINE STOP AND EMERGENCY STOP PROCEDURE 6-49
8.3.8 ENGINE START AND RESET PROCEDURE 6-49
8.4 CHECKING AFTER CRANE OPERATION 6-50
9. TROUBLE SHOOTING 6-51
9.1 BEFORE THE TROUBLE SHOOTING 6-51
9.2 ERRORS IN THE REMOTE CONTROL DEVICES 6-52
10.SYSTEM SPECIFICATIONS 6-54
ENGINE AND ELECTRIC MOTOR SPECIFICATIONS
7- 1
1. PRECAUTIONS (FOR ENGINE AND ELECTRIC MOTOR SPECIFICATION) 7- 2
2. SAFETY LABEL LOCATIONS 7- 3
3. MACHINE EACH SECTION 7- 5
3.1 MACHINE EACH UNIT 7- 5
3.2 TRAVELING AND CRANE OPERATION UNITS 7- 6
3.3 INSTRUMENT PANEL SECTIONS 7- 7
3.4 POWER UNIT 7-10
3.5 POWER SUPPLY BOX 7-10
3.6 INVERTER UNIT 7-11
4. OPERATION 7-14
4.1 CHECKING BEFORE OPERATION 7-14
4.1.1 CHECKING BEFORE STARTING ELECTRIC MOTOR (VISIBLE CHECKS) 7-14
4.1.2 CHECKING BEFORE STARTING ELECTRIC MOTOR 7-14
4.1.3 CHECKING AFTER STARTING ELECTRIC MOTOR 7-14
4.2 POWER SUPPLY CONNECTION 7-15
4.3 OPERATION AND CHECKING AFTER POWER CONNECTION 7-17
4.4 MACHINE OPERATION 7-19
4.5 MACHINE STOP AND CHECKS AFTER STOPPING MACHINE 7-19
4.6 POWER SUPPLY SEPARATION 7-20
5. LONG-TERM STORAGE 7-21
6. ELECTRIC MOTOR TROUBLESHOOTING 7-22
7. PRINCIPLE SPECIFICATION LIST 7-23
8. SPECIFICATION DIMENSINAL DRAWING 7-24
