Maeda MC-305C-2 - Page 6

0-4
ITEM
Page
8.7 MAINTENANCE EVERY 50 HOURS 4-24
8.8 MAINTENANCE EVERY 250 HOURS 4-28
8.9 MAINTENANCE EVERY 500 HOURS 4-32
8.10 MAINTENANCE EVERY 1000 HOURS 4-36
8.11 MAINTENANCE EVERY 1500 HOURS 4-45
8.12 MAINTENANCE EVERY 2000 HOURS 4-45
SPECIFICATIONS
5- 1
1. SPECIFICATION LIST 5- 2
2. SPECIFICATION DIMENSIONAL DRAWING 5- 4
3. DIMENSIONAL DRAWING OF OUTRIGGER WIDTH 5- 5
4. RATED TOTAL LOAD TABLE 5- 6
5. WORKING RADIUS AND LIFTING HEIGHT 5- 9
INTERACTIVE REMOTE CONTROL
6- 1
1. OUTLINE OF REMOTE CONTROLLER 6- 2
1.1 FEATURE 6- 2
1.2 CONFIGURATION 6- 2
1.3 FUNCTIONS OF REMOTE CONTROL SYSTEM 6- 3
2. SAFETY PRECAUTIONS 6- 4
2.1 For Safety Operations 6- 4
2.2 PRECAUTIONS FOR CRANE OPERATION 6- 6
2.2.1 PRIOR TO STARTING ENGINE 6- 6
2.2.2 SUBSEQUENT TO STARTING ENGINE 6- 7
2.2.3 TERMINATING THE OPERATION 6- 7
3. LOCATIONS OF SAFETY LABELS 6- 8
4. COMPONENTS OF THE TRANSMITTER 6-10
5. COMPONENTS OF THE RECEIVER 6-16
5.1 COMPONENTS OF THE RECEIVER 6-16
5.2 FUSE IN THE RECEIVER 6-18
6. SETTING UP OPERATION MODES OF TRANSMITTER 6-20
6.1 A MODE 6-20
6.1.1 OPENING A MODE SCREEN 6-20
6.1.2 MESSAGES IN THE A MODE SCREEN 6-20
6.1.3 AN EXAMPLE FOR SETTING IN THE A MODE 6-24
6.2 PROCEDURE IN THE OPERATION MODE 6-25
6.2.1 CALL OUT CRANE MODE 6-25
6.2.2 CALL OUT OUTRIGGER MODE 6-26
7. CHECKING BEFORE OPERATION 6-28
7.1 CHECKING BEFORE STARTING ENGINE 6-28
7.1.1 CHECKING BEFORE TURNING ON THE TRANSMITTER 6-28
7.1.2 CHECKING AFTER TURNING ON THE TRANSMITTER 6-29
7.1.3 CHECKING RECEIVER 6-32
7.2 CHECKING AFTER STARTING ENGINE 6-33
7.2.1 VERIFICATION FOR THE ENGINE START AND STOP 6-33
7.2.2 CHECKING “OUTRIGGER MODE” OPERATION 6-34
7.2.3 CHECKING “CRANE MODE” OPERATION 6-36
