MAINTENANCE AND LUBRICATION GRT8120 OPERATOR MANUAL
6-38 Published 3-22-2021, Control # 702-02
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
Boom Lubrication (Continued)
86
Tele 6 Rear Upper
Wear Pad
Figure 6-20 M
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 45.
87
Tele 5 Rear Upper
Wear Pad
Figure 6-20 M
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 45.
88
Tele 4 Rear Upper
Wear Pad
Figure 6-20 M
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 45.
89
Tele 3 Rear Upper
Wear Pad
Figure 6-20 M
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 45.
90
Tele 2 Rear Upper
Wear Pad
Figure 6-20 M
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 45.
91
Tele 1 Rear Upper
Wear Pad
Figure 6-20 M
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 45.
92
Tele 1 Lock Pin Figure 6-20 N
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 46.
93 Tele 2 Lock Pin Figure 6-20 N
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 46.
94 Tele 3 Lock Pin Figure 6-20 N
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 46.
95 Tele 4 Lock Pin Figure 6-20 N
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 46.
96 Tele 5 Lock Pin Figure 6-20 N
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 46.
97 Tele 6 Lock Pin Figure 6-20 N
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 46.
NOTE 45: DO NOT apply excessive pressure or force when greasing wear pads. Applying excessive pressure or force
can cause grease fitting to separate from wear pad. Apply grease only until resistance is felt.
NOTE 46: To grease rear upper-wear pads, front wear pads, and locking pins on each Tele Section, follow the Tele Section
positioning and lubrication instruction given in the section titled READ FIRST! IMPORTANT CRANE SET-UP
INFORMATION!, page 6-33 of this GRT8120 Operator Manual. Start with Tele Section 6 (Tele 6). See also your
GRT8120 Service Manual for detailed service interval and specified boom lubrication instructions.
