MID-EXTEND
7376009373
MID-EXTEND
2” WIDE WHITE
REFLECTIVE
TAPE
THIS CRANE IS NOT INSULATED.
TO AVOID DEATH OR SERIOUS INJURY
Keep ALL parts of the crane, rigging and load at least 20 feet
(6 meters) away from any energized power line. You MUST
follow the OSHA requirements set forth in 29CFR 1926.1407
through 1926.1411.
This crane is not designed or equipped for use within 10 feet
(3 meters) of energized power lines [Refer to 29CFR1926.1410
Table A]. If operation within 10 feet (3 meters) of any power
lines cannot be avoided, the power utility MUST be notified
and the power lines MUST be de-energized and grounded
BEFORE performing any work.
If contact is ever accidentally made with a power line and any
part of this crane, its rigging or load, NEVER touch the crane
or even approach or come near the crane.
Electrocution CAN OCCUR even without direct contact with
the crane.
DANGER
80037260
ELECTROCUTION HAZARD
EACH SIDE OF
ALL O/R BEAMS
FRONT & REAR
O/R BEAMS
FRONT & REAR
O/R BEAMS
EACH SIDE OF
ALL O/R BEAMS
2” WIDE WHITE
REFLECTIVE
TAPE
CAUTION
DO NOT USE FOR LIFTING
7376007249
G7
DANGER
BURN HAZARD
TO AVOID DEATH OR SERIOUS
INJURY:
Do Not Use Ether. Engine
equipped with electric heater
starting aid. Use of ether may
cause explosion.
7376101881
FILL SLEW DRIVE GEARBOX
TO BOTTOM OF FILL HOLE
80126944G7
FILL SLEW DRIVE BRAKE
TO TOP OF ELBOW
80126943G7
170
130
3
144
141
141
143
3
27
171
145
80113724 B6
FIGURE A-1 continued
10087-6
