McHale Fusion 2 - Hydraulic System Valve Assembly

McHale Fusion 2 hydraulic systems overview section
12-9
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
CVA00015
12.6.3: Hydraulic system: valve assembly
CVA00015
Ports Description Part Code Dowty Seals
A1 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
A2 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
A3 1/2"-1/2" M/M ADAPTOR CHY02013 CHY00053
A4 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
A5 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
B1 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
B2 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
B3 1/2"-1/2" M/M ADAPTOR CHY02013 CHY00053
B4 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
B5 1/2"-3/8" M/M ADAPTOR CHY02008 CHY00053
T1 3/4"-3/8" M/M ADAPTOR CHY02263 CHY02012
P1 3/4"-3/8" M/M ADAPTOR CHY02263 CHY02012
