McHale Fusion 2 - Section Page

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Section Page
McHale Fusion 2 contents section
02-iii
10. Machine maintenance
10.1 Maintenance intervals………………………………………. 10-1
10.2 Maintenance intervals/ recommended service……….. 10-2
10.2.1 Replace cam bearings………………………………... 10-3
10.2.2 Check key way on pick-up reel sprocket ……………. 10-3
10.2.3 Check chain tensioners………………………………. 10-4
10.2.4 Chain tension adjustment………………………….. .. 10-4
10.2.5 Check for broken magnets on the knife unit……….. 10-5
10.2.6 Ensure all oiler pipes to the chain and grease pipes
to the bearings are not damaged…………………… 10-5
10.2.7 Check roll pins/ bolts on the knife holder bracket…. 10-6
10.2.8 Check spiral pins on tine bars………………………. 10-6
10.2.9 Check spur gears……………………………………... 10-7
10.2.10 Replace bearing on pick up reel shaft……………… 10-7
10.2.11 Grease pick up reel shaft and slip clutch bearing… 10-8
10.2.12 Check left/ right auger……………………………….. 10-9
10.2.13 Replace rotor drive side bearing………………….… 10-10
10.3 Density pressure check …………. .….…………………… 10-11
10.4 Replace nilos ring ………………..………………………… 10-12
10.4.1 Check bolts on chamber door hinges …………...…. 10-13
10.4.2 Remove top door chamber panels and blow out …… 10-14
10.4.3 Check brake pads on dispenser ring………………… 10-15
10.4.4 Replacing ring brake pads ……….. ….……………… 10-16
10.4.5 Lubricate wrapper roller drive chains ...……………… 10-17
10.5 Check dispenser for tack/ glue build up ……………….... 10-18
10.5.1 Grease dispenser springs..…………………………… 10-18
10.5.2 Clean cut and tie rails…….………………...………… 10-19
10.5.3 Check cut and tier bearing alignment………………. 10-19
10.5.4 Clean and oil all chains and grease all bearings….... 10-20
10.5.5 Clean the netter unit and apply grease………………. 10-20
10.5.6 Apply grease to exposed ram rods….………………. 10-20
10.5.7 Clean & lubricate the rollers in the bale chamber…. 10-20
10.5.8 Apply oil/ spray grease to the knifes ….………………. 10-20
10.5.9 Change the gearbox oil…………...….………………. 10-20
10.5.10 Apply oil/ spray grease to the knifes ….……………. 10-20
10.5.10 Start of season machine preparation…………..…… 10-21
10.5 Chain Adjustment………………………….……………….... 10-22
10.6.1 Main drive chain adjustment..…………………………… 10-22
10.6.2 Bottom chamber chain adjustment..…………………… 10-22
10.6.3 Top chamber chain adjustment..……………………... 10-23
10.6.4 Bottom door to drive chain adjustment..……………… 10-24
10.6.5 Pick up reel tine chain adjustment..…………………… 10-24
10.6.6 Reel chain adjustment………………………………….. 10-24
10.6.7 Chopper unit duplex chain adjustment………………… 10-25
