McHale Fusion 2 maintenance section

10-8

McHale Fusion 2 round baler wrapper technical service manual

Issue 1: 0208

10.2.11 Grease pick-up reel shaft bearing and slip

clutch shaft bearing

Grease Pick-up Reel Shaft

Bearing (CBR00092)

Grease Slip Clutch Shaft Bearing

(CBR00094)
