McHale Fusion 2 maintenance section

10-10

McHale Fusion 2 round baler wrapper technical service manual

Issue 1: 0208

10.2.13 Replace rotor bearing on drive side

Replace rotor bearing on drive

side of the machine every

20,000 bales.

Rotor Bearing

(CBR00078)
