McHale Fusion 2 - Wrapper Operation; Loading Plastic Film

McHale Fusion 2 wrapper operation section
08- 1
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
8. Wrapper operation
The McHale Fusion 2 is designed with a wrapping system with two plastic film
dispensers. Differing to conventional wrappers, the dispensers move vertically
around the bale. The dispenser carrier system is mounted directly behind the baler
chamber. Although the dispenser carrier ring is well protected by the safety guards
and electrical safety switches the operator must ensure that all people and animals
are kept out of this region while operating the machine.
Warning! Keep all persons outside of the “danger zone” during all machine
operations! See section 4.9 for “danger zone” description.
8.1 Loading plastic film
1. Release the rubber safety latch and lock in order to open the dispenser access
door on the left hand side of the machine, see figure 8.11 (see opposite page
for figures).
2. Remove the linch pin and release the dispenser film roll lock, see figure 8.12.
3. Remove the old core.
4. Push the new roll on the central pin, engage the film roll lock and reinsert the
linch pin.
5. Thread the film through the dispenser rollers as per the threading diagram,
see figure 8.13, taking care not to trap fingers between the rollers.
6. Pull approximately 1.5 m of film away from the dispenser and make a knot at
the end of the plastic film, see figure 8.14.
7. Close the dispenser safety door.
8. Push the rear mounted dispenser park button, for approx. two seconds, in
order to rotate the next dispenser to the loading or “home” position, see figure
8.15. Note: The dispenser ring can only rotate when the safety door is closed
and the control box must be in “Auto” mode when pressing this button.
9. Open safety door and load film as before.
10. Pull approx. 1.5 m of film away from the dispenser and make a knot at the end
of the plastic film as before.
11. Slot the knotted end of the film in the left hand side slot of the rear wrapping
roller as shown in figure 8.16.
12. Grab hold of the dangling film on the right hand dispenser and slot the knotted
end of the film in the right hand side slot of the rear wrapping roller as shown in
figure 8.17.
13. Close the door firmly and fasten the safety door with the rubber safety
latch.
Warning!
Do not attempt to clamp plastic film in the “cut & hold” itself, this
action may result in serious injury!
Note:
Pushing “Resume” on the control box will complete the wrapping of a bale,
that is interrupted by an “Out of film” error symbol shown figure 8.18.
