McHale Fusion 2 - Table of Contents

McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
McHale Fusion 2 contents section
02-ii
Section Page
7. Baler requirements and preparation
7.1 Net requirements…………………………………………... 07-1
7.2 Care of the net roll ……………………………………... 07-1
7.3 Care of the net wrapping system……………………….. 07-1
7.4 Loading netter system……………………………………. 07-2
7.5 Net cutter setting………………………………………….. 07-3
7.6 Net tension bar setting……………………………………. 07-4
7.7 Chopper unit knife removal and installation…………. 07-5
7.8 Automatic lubrication system ……………………….... 07-7
7.9 Gear box oil………………………………………………… 07-8
7.10 Tyre inflation pressures ………………………………. 07-8
7.11 Drawbar and PTO shaft stand usage…………………. 07-9
7.12 Drawbar adjustment ………………………………. 07-11
7.13 PTO shaft adjustment ………………………………. 07-11
8. Wrapper operation
8.1 Loading plastic film ……………………………………. 08-1
8.2 Plastic film requirements ……………………………... 08-3
8.3 Wrapping process ……………………………………. 08-4
8.4 Dispenser adjustment ……………………………… 08-4
8.5 Cut and hold system ……………………………………. 08-5
Cut and hold Rail Adjustment…………………… 08-6
Cut and hold horizontal position adjustment…... 08-6
8.6 Dispenser gear options ……………………………….. 08-7
9. Baler field operation and adjustments
9.1 Break in period………………………………………….. 09-1
9.2 Swath preparation ……………………………………. 09-1
9.3 Pick-up adjustment ……………………………………. 09-2
9.4 Crop guard adjustment ……………………………... 09-2
9.5 Unblocking system ……………………………………. 09-3
9.6 Chopping system …………………………………… 09-4
9.7 Knife pressure gauge …………………………………. 09-4
9.8 Bale density gauge ……………………………………. 09-5
9.9 Setting chamber pre-charge pressure…………… 09-5
9.10 Chamber door lock ……...……………………… 09-6
9.11 Spare film holders and door safety latch operation 09-6
9.12 Adjusting pick-up float spring ……………………….. 09-7
