McHale Fusion 2 - Oiler and Greaser System; Fittings at Block

McHale Fusion 2 hydraulic systems overview section
12-31
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
12.12.4: Oiler and greaser system; fittings at blocks:
CHY00201 OIL MASTER BLOCK
Ports Part Code Description Qty
1,2,4,5,6 & 8 CFA00682 COMPRESSION NUT 6
CFA00683 BRASS OLIVE 6
CHY00202 SECONDARY OIL BLOCK
1-5 & 6 CFA00682 COMPRESSION NUT 6
CFA00684 BRASS OLIVE 6
CHY00209 GREASE MASTER BLOCK
Ports Part Code Description Qty
1,2,5,6 & 8 CFA00648 CHECK VALVE 5
CFA00545 STEEL OLIVE 5
CFA00544 COUPLING NUT 5
CHY02324 HOSE STUD STRAIGHT 5
CHY02325 THREADED SLEEVE 5
CHY00208 BLOCK MIDDLE DOOR
Ports Part Code Description Qty
1&2, 4-10 CFA00648 CHECK VALVE 9
CFA00545 STEEL OLIVE 9
CFA00544 COUPLING NUT 9
CHY00207 BLOCK TOP DOOR DS
Ports Part Code Description Qty
1-3 & 5-7 CFA00648 CHECK VALVE 9
CFA00545 STEEL OLIVE 9
CFA00544 COUPLING NUT 9
CHY00206 BLOCK TOP DOOR NDS
Ports Part Code Description Qty
1-6 & 8-10 CFA00648 CHECK VALVE 9
CFA00545 STEEL OLIVE 9
CFA00544 COUPLING NUT 9
CHY00205 BLOCK BOTTOM DOOR DS
Ports Part Code Description Qty
1,2,3,5 & 6 CFA00648 CHECK VALVE 5
CFA00545 STEEL OLIVE 5
CFA00544 COUPLING NUT 5
CHY00204 BLOCK BOTTOM DOOR NDS
Ports Part Code Description Qty
1,2,4,5 & 6 CFA00648 CHECK VALVE 5
CFA00545 STEEL OLIVE 5
CFA00544 COUPLING NUT 5
