McHale Fusion 2 hydraulic systems overview section
12-33
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Item Part Code Description Qty
12 CFA00549 6LL FITTING STRAIGHT 32
13 CFA00543 6LL FITTING ELBOW 24
14 CFA00681 6LL UNION (COMPLETE) 3
16 CFA00544 6LL COUPLING NUT 25
19 CFA00545 STEEL OLIVE 25
20 CHY02323 HOSE STUD ELBOW 1
21 CHY02324 HOSE STUD STRAIGHT 9
22 CHY02325 THREADED SLEEVE 10
