McHale Fusion 2 - Page 164

McHale Fusion 2 drive systems section
13-3
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Item Part Code Description Qty
1 CMT00105 Gear Case 1
3 CBR00104 Bearing Housing 2
5 CMH00901 Shaft 2
6 CMH00902 Bevel Gear Pair 1
8 CMH00903 Bush 2
11 CBR00113 Ball Bearing 2
13 CBR00114 Taper Roller Bearing 2
15 CBR00115 Taper Roller Bearing 1
16 CBR00116 Circlip 1
18 CFA00652 Slotted Round Nut 2
21 CFA00653 Radial Seal 1
22 CSE00132 Radial Seal 1
24 CSE00133 Shim 2
30 CFA00654 Shim 2
31 CFA00655 Shim 1
32 CFA00656 Shim 1
33 CFA00657 Shim 1
39 CFA00658 Shim 2
40 CFA00659 Shim 2
41 CFA00660 Shim 2
42 CFA00661 Shim 1
44 CFA00662 Cylindrical Dowel 2
45 CFA00065 Hexagon Headed Screw 16
47 CMT00072 Breather Screw 1
48 CSE00127 Gasket 2
50 CMT00073 Hexagon Head Plug 2
