McHale Fusion 2 technical specification section
15-1
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
15. Technical specifications
15.1 General dimensions/specifications
Transport length: 5.8 m (19’1”)
Transport width : 2.76 m (9’ 1”)
Transport height: 3.02 m (9’ 11”)
Transport weight: 5700 kg (12566 lbs)
Tyre dimensions: 550/60 – R22.5
Tyre pressure: 1.65 bar/24 P.S.I.
Tyre dimensions (Pick-up reel): 170/60 – 8
Tyre pressure (Pick-up reel): 1.38 bar/20 P.S.I.
Maximum road speed: 40 km/h (25 mph).
Brake system: Hydraulic brakes (Cemagref approved)
Air brakes* (TUV approved)
15.2 Tractor attachment
Drawbar: Low drawbar.
High drawbar*.
Pto Speed: 540 rpm.
Lighting: 12 V / 7 pin socket.
Electrics: 12 V / 20 Amp euro socket.
Hydraulic system: load sensing, open centre,closed centre.
Min. pressure: 180 bar (2650 P.S.I).
Min. flow rate: 45 l/min (8.79 gal/min) @ 180 bar (2650 P.S.I)
15.3 Machine specifications
Bale chamber diameter: 1.25 m (49”)
Bale chamber width: 1.23 m (48”)
Pick-up width: 2.00 m (78”)
Net tying: net width Max. 1.26 m (49.5”)
net length 2000 m / Max 3000 m (2187 yd./Max 4374 yd.)
Plastic film: film width 750 mm (29½”)
film stretch 70% (55% optional)
film layers 2+2; 2+2+2;etc.
film storage 8 Rolls (+ 2 Rolls on dispenser)
Dispenser rotary speed: Max. 30 rpm
(*) May not be available in all countries, check with your McHale Importer for availability in your
country. Units are given in both metric and UK imperial values, with the latter shown in brackets.
Check with
national road traffic
regulations in the
individual country!
