McHale Fusion 2 technical specification section
15-3
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
15.5 Tyre specifications
Tyre type Pressure
¾ 550/60 – 22.5 or 550/60 R 22.5 1.38 bar (20 P.S.I).
¾ 650/55 R 22.5 (Optional specification) 1.38 bar (20 P.S.I).
¾ 170/60 – 8 (Pick-up tyre) 1.38 bar (20 P.S.I).
15.6 Declaration of conformity
The McHale Fusion complies with the EU provisions as per the 98/37/EC machinery
directive, the 89/336/EEC EMC directive and is manufactured to the I.S. EN ISO
9001:2000 quality standard.
The following harmonised standards were applied:
EN 292: Safety of machinery-Basic concepts, general principles for design:
Part 1: Basic terminology, methodology.
Part 2: Technical principles and specifications.
EN 1553: Agricultural machinery – Agricultural self propelled mounted, semi-
mounted and trailed machines – Common safety requirements.
EN 704: Agricultural machinery – Pick-up balers – Safety.
