McHale Fusion 2 specific section
05-10
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
5.9 Machine lifting eye location points
Right hand side lift hook Front view Left hand side lift hook
Rear view
Fig. 5.91 Machine lifting eye locations
Warning!
¾ Only use chains or strapping that are rated for a minimum load of two tonnes
(2,000 kg’s) per chain or strap when using the four lift eye locations on the
chassis, shown above.
¾ The crane or lifting device must be capable of lifting a minimum load of seven
tonnes (7,000 kg’s).
¾ Never go under a suspended machine or attempt to try and stop it if moving
erratically, death or serious injury may result.
¾ Always be observant of people and objects around the suspended machine
and do not allow the machine to impact heavily on the ground after suspension
or movement
