McHale Fusion 2 maintenance section

10-13

McHale Fusion 2 round baler wrapper technical service manual

Issue 1: 0208

Check bolts on all door hinges. Ensure all bolts are secure and the hinge joints

are tight. Replace any damaged bolts or hinges.

Bolt

CFA00586

10.4.1: Check the bolts on chamber door hinges
