JET DRIVE
90-826883R2 JUNE 1998 Page 6B-19
3. After setting the impeller height, tighten the impeller nut snug with a wrench. Secure
impeller nut by bending tabs (a) against the flats on the impeller nut.
a
a - Tabs
4. Reinstallthewaterintakehousingwithsixbolts.Checkclearancearoundtheimpeller
to make sure the water intake housing is centered and not rubbing against the liner.
Torque mounting bolts to 100 lb. in. (11.3 N·m).
NOTE: If the outboard is used in salt water, apply Quicksilver Anti-Corrosion Grease
aroundtheentiremountingflangeonthewaterintakehousingandalso to the threadson
the six mounting bolts.
