Air Intake Components

Ref. No. Qty. Description

Torque

Nm lb‑in. lb‑ft

1 2 Washer

2 2 Screw 6.0 53.1 –

3 1 Screw 6.0 53.1 –

4 1 Air box

5 1 Hose

6 1 Throttle body assembly

7 1 Idle air control valve

8 2 Screw 3.0 26.6 –

9 2 Screw 3.0 26.6 –

10 1 TMAP sensor

11 1 Gasket

12 1 Restrictor (10/15 hp models only)

13 1 Gasket

14 2 Rubber mount

15 2 Collar

16 1 Breather hose

17 1 Hose clamp

18 2 Nut 6.0 53.1 –

19 2 Washer

Service Procedures
