5. Slide the pump cover onto the driveshaft. While pushing down on the water pump cover, rotate the driveshaft clockwise to
install the pump cover over the impeller.
6. Secure the water pump cover with four screws. Tighten the screws to the specified torque.
a - Screws (4)
b - Water pump cover
Description Nm lb‑in. lb‑ft
Water pump cover screws 6.0 53.1 –
Propeller Shaft and Bearing Carrier Installation
1.
Apply 2‑4‑C with PTFE to the bearing carrier O‑ring.
Gear Housing (2.15:1)
Page 6A-38 © 2018 Mercury Marine 90-8M0125265 eng NOVEMBER 2017
