Steering Arm and Copilot Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Steering arm
2 2 Thrust plate
3 2 Bushing
4 1 O‑ring
5 2 Screw (M8 x 85) 13 115 –
6 2 Washer
7 1 Starboard mount bracket
8 2 Lower rubber mount
9 1 Lower damper
10 1 Port mount bracket
11 1 Screw (M6 x 20) 6.0 53.1 –
12 1 Anode
13 1 Ground wire (driveshaft housing to lower mount bracket)
14 1 Screw (M6 x 10) 6.0 53.1 –
15 1 Ground wire (swivel bracket to lower mount bracket)
16 1 Grease fitting
17 2 Upper rubber mount
18 4 Screw 13 115 –
19 2 Screw
20 2 Upper rubber damper
21 1 Upper damper
22 2 Washer
23 2 Locknut 27.0 – 19.9
24 1 Copilot assembly
25 1 Locknut 11.0 97.3 –
26 1 Washer
27 1 Washer
28 1 Copilot handle
29 2 Disc
30 2 Screw (M6 x 16) 6.0 53.1 –
31 1 Copilot plate
32 1 Washer
33 1 O‑ring
34 1 Copilot threaded rod
Clamp/Swivel Bracket and Driveshaft Housing
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 5A-11
