Driveshaft Housing Cover Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Front panel
2 1 Warning light
3 1 Fuel connector
4 1 Screw 6.0 53.1 –
5 1 Grommet
6 1 Grommet
7 1 Grommet
8 1 Front cover stay
9 2 Rivet
10 1 Start switch (tiller handle, electric start models)
11 1 Grommet
12 2 Mount
13 2 Rubber mount
14 2 Collar
15 2 Washer
16 2 Washer
17 2 Screw 6.0 53.1 –
18 1 Starboard driveshaft housing cover
19 1 Port driveshaft housing cover (manual tilt models)
20 1 Port driveshaft housing cover (power tilt models)
21 10 Screw 6.0 53.1 –
22 1 Rigging ingress grommet
23 1 Cowl latch assembly
24 1 Screw 6.0 53.1 –
25 1 Washer
26 1 Decal
27 1 Power tilt switch (power tilt models)
28 1 Gasket (power tilt models)
29 1 Switch box (power tilt models)
30 1 Switch box grommet (power tilt models)
31 2 Screw (power tilt models) 2.5 22.1 –
32 1 Top cowl seal
