Throttle and Shift Components (Tiller Models)
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Starboard horizontal shift shaft bracket
2 1 Port horizontal shift shaft bracket
3 4 Screw 6.0 53.1 –
4 1 Neutral start switch
5 1 Bracket
6 1 Screw 6.0 53.1 –
7 1 Switch actuator
8 1 Screw 6.0 53.1 –
9 1 Short detent spring
10 2 Detent spring
11 1 Shift cable assembly
12 3 Plastic washer
13 3 Retaining clip
14 1 Lower shift arm
15 1 Upper shift arm
16 1 Horizontal shift shaft
17 1 Bushing
18 2 Washer
19 1 Screw 6.0 53.1 –
20 1 Vertical shift shaft
21 1 Shift shaft coupler 4.0 35.4 –
22 1 Jam nut 4.0 35.4 –
23 1 Grommet
24 1 Throttle link rod assembly
25 2 Ball joint connector
26 2 Jam nut 3.0 26.6 –
27 1 Throttle rod
28 1 Screw 6.0 53.1 –
29 2 Washer
30 1 Bushing
31 1 Throttle drum assembly
32 1 Ball joint
33 1 Throttle and shift cable bracket
34 3 Screw 6.0 53.1 –
35 2 Screw
36 1 Cable latch
Throttle and Shift Linkage
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 7A-5
