Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
47 1 Throttle handle outer grip
48 1 Inner throttle handle
49 1 Throttle shaft
50 1 Tension clamp
51 1 Compression spring
52 1 Plain washer
53 1 Cotter pin
54 1 Washer
55 1 Tiller handle adjusting nut
56 1 Tiller handle bracket
57 1 Pan head screw 2.3 20.3 –
58 1 Self‑tapping hex head screw 2.0 17.7 –
59 1 Pulley cover
60 1 Throttle cable pulley
61 1 Throttle cable case
62 1
Tiller handle with tilt harness assembly
Tiller handle harness assembly
63 1 Grommet
64 1 Plastic nut 2.0 17.7 –
Tiller Handle
Page 7B-6 © 2018 Mercury Marine 90-8M0125265 eng NOVEMBER 2017
