Recoil Starter Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Handle cap
2 1 Handle
3 1 Seal
4 1 Recoil starter housing
5 1 Lock cable
6 1 Lock cam spring
7 1 Caution decal
8 3 Screw with nylon lock patch (M6 x 20) 6.0 53.1 –
9 3 Washer
10 1 Lock spring
11 1 Lock
12 1 Cam gear cover
13 1 Vent tank
14 3 Screw
15 2 Grommet
16 1 Starter rope
17 1 Spring
18 1 Tapping screw
19 1 Bushing
20 1 Sheave
21 1 Starter pawl
22 1 Starter pawl guide
23 1 Return spring
24 1 Starter shaft screw 6.0 53.1 –
25 1 Friction plate
26 1 Friction plate spring
Recoil Starter
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 8A-5
