Mercury 20 EFI FourStroke Service Manual

Starter Motor Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Starter motor assembly
2 1 Pinion assembly
3 1 Washer
4 1 Brush card
5 2 Screw (M4 x 8) 1.5 13.3 –
6 1 Bushing
7 2 Screw 6.0 53.1 –
8 2 Lockwasher
9 2 Washer
10 1 O‑ring
11 1 Bushing
12 1 Washer
13 2 Lockwasher (M6)
14 2 Nut 4.0 35.4 –
Charging and Starting Systems
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 2B-5
