Handling of Consumables 47
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual logiJET T4-2 /T6-2 /RFID Edition 2.2
1. Open the printer hood.
2. Release the printhead pressure lever.
Fig. 5.4.b Swivel the printhead pressure lever upward (counterclockwise).
3. Please adjust the lateral positions of the thermal printhead
spring boxes in accordance to the current material width.
Normally, the wider the paper, the farther the spring boxes on
the right side have to be positioned from the center wall (and
vice versa for small labels).
Fig. 5.4.c Lateral shifting of the spring boxes
