9−1. Analog output
Warning ● When power ON the instrument with the external HOLD signal
shorted, analog output will be as follows :
1
Even when the Display is targeted for HOLD with the FUNC−50,
analog output outputs the least value if the target for analog
output is set as Display.
2
When an option is assumed to be the target for HOLD with the
FUNC−50, analog output outputs the least value.
3
Other than the case above ① and ②, present load value is
outputted.
● When the CHECK SW is applied, pay attention to the following
points.
1
By ON operation of CHECK, the instrument isn’t in Measurement
mode any more, (RUN display puts off. RUN output is open),
however, analog option will continue to output.
2
By ON operation of CHECK, “OL” error display(Analog output
will output when OVR.) might be shown.
Referring to RUN display, take care not to use the analog output
during ON operation of CHECK.
● The following 5 kinds of options are described for the analog outputs.
D CSD814B−P07
D CSD814B−P23
D CSD814B−P24
D CSD814B−P25
D CSD814B−P26
9−1−1.
Related function.
FUNC−16
Selection of target for analog
output
Display, Net weight, Gross weight
FUNC−17
Display value at the minimum
value of analog output
FUNC−18
Display value at the maximum
value of analog output
FUNC−19 Form of analog output Relative value/Absolute value output
