7−14. Check mode

The following checks can be made in the check mode.

・ Confirmation of ROM version.

・ Confirmation on bridge voltage.

・ Confirmation on installed options.

・ Confirmation on control input.

・ Confirmation on contact output.

・ Confirmation on analog output(option).

・ Confirmation on BCD output(option).

・ Confirmation on connection with digital interface(option)

● Each confirmation on analog output, BCD output and connection

with digital SW interface can be operated only when individual

corresponding option is installed.

● In the Check mode, measurement mode can be returned back by

pressing the key.
