36
6−5. key
6−5−1.
Press key in the Measurement mode.
10
0
digit at set vale of comparator S4 will flash, then setting for set value of comparator S4 will
be possible.
Moreover, if any key operation is not made during 20 s approximately, that is, untouched, the
mode will be returned to the measurement mode automatically.
By pressing the key, changed set value will be registered internally, the condition of
available setting for S4 can be closed.
6−5−2.
When operated in fine adjustment mode for ZERO and SPAN.
“UP” operation of fine adjustment for ZERO and SPAN can be made.
6−5−3.
When operation is made in the other mode.
(1)
Decrement of set value
When the key is pressed with the condition of displaying various kinds of set value, set
value will decrease at one decrement, such as 0, 9, 8, 7, 6, 5, 4, 3, 2, 1, and 0, one by one.
● In the operation in the paragraph 6−5−2. and 6−5−3., when the key
is pressed for more than 2 s, each key operation will be executed
continuously at a constant interval without the operation of ON/OFF.
6−6. key
6−6−1.
When pressed in Measurement mode.
Function mode can be entered, then “FUNC” will be shown on load display. From this status,
setting of function or shift to another mode can be available.
From the condition of various kinds of modes, measurement mode can be shifted by pressing the
key.
6−6−2.
When operated in the fine adjustment mode for ZERO and SPAN
The target for coarse adjustment and fine adjustment can be changed by ZERO/SPAN. At the
same time, S3 display on setting display will change “ZERO” to “SPAN”.
6−6−3.
when operation is made in the other mode.
From the condition of various kinds of modes, measurement mode can be shifted by pressing the
key.
