40
7−2. Comparator
The instrument prepares comparator consisting of 4 pieces set values S1, S2, S3, and S4, and also
comparator (SO) that can change operation by the setting of Function FUNC−13.
Warning ● The comparator in the instrument executes comparative operation
and synchronous with load display. In due course, there may be cases
that judgement display and contact output operate even when the
load display doesn’t reach to comparator set value.
7−2−1.
Change of set value
Warning ● When the set value for comparator is set wrong, or set in wrong
procedures, it may not obtain the correct results from the comparator,
and it may cause a malfunction in peripheral equipments and also
cause a damage as well.
● This comparator continues the comparative operation even when
changing the set value.
● The set value is limited up to 110 % of the maximum display value.
● By the continuous key operation, set value can be increased/decreased
continuously.
To Next Page
