Minebea CSD-814B User Manual

86
9. Options
As for options for the instrument, 10 kinds of outputs and interfaces and so on, and 3 kinds of power
supply voltage are prepared.
1
Current output [4 mA to 20 mA] P/N CSD814B−P07
2
Voltage output [0 V to 1 V] P/N CSD814B−P23
3
Voltage output [0 V to 5 V] P/N CSD814B−P24
4
Voltage output [0 V to 10 V] P/N CSD814B−P25
5
Voltage output [1 V to 5 V] P/N CSD814B−P26
6
BCD output P/N CSD814B−P15
7
RS−232C interface P/N CSD814B−P74
8
RS−422 interface P/N CSD814B−P76
9
Serial interface P/N CSD814B−P77
10
Digital switch interface P/N CSD814B−P78
11
Power supply voltage AC200 V P/N CSD814B−P63
As for the options from ① to ⑩, there are limitations of combinations according to the below table.
P07 P23 P24 P25 P26 P15 P74 P76 P77 P78
P07
− × × × × ○ ○ ○ ○ ○
P23
× − × × × ○ ○ ○ ○ ○
P24
× × − × × ○ ○ ○ ○ ○
P25
× × × − × ○ ○ ○ ○ ○
P26
× × × × − ○ ○ ○ ○ ○
P15
○ ○ ○ ○ ○ − × × × ×
P74
○ ○ ○ ○ ○ × − × × ×
P76
○ ○ ○ ○ ○ × × − × ×
P77
○ ○ ○ ○ ○ × × × − ×
P78
○ ○ ○ ○ ○ × × × × −
Optional combinations ○ : Possible × : Impossible
