7−3. How to use filter
This instrument prepares digital filter that stabilizes data converted into digital though calibration
process.
Warning When setting filter is not suitable, correct measurement can’t be
made and it may cause an unexpected accident, so care should be
taken fully.
7−3−1.
Digital filter
Digital filter in the instrument can be set from “000000” to “000007”.
Averaged−out times of digital filter can be decided from the set value(Related function
FUNC−04).
As for default, “000003” has set.
The relations between setting and average−out times are as follows:
(Average−out times) 2
n+1
n: Value at 10
0
digit of set value.
For example, when setting is “000003”, averaged−out times are as follows:
(Averaged−out times) 2
3+1
16 (times)
The tendency of characteristics by averaged−out times is listed below:
Averaged out times
a few many
Resist to noise
rapid stable
Response speed
quick slow
