(3)

When the operation of “contact ON less than or equal to set value” is selected at S1, and

effective direction for hysteresis is set as “ON delay”.

Display

OFF

S1 Set value

Hysteresis time width

Time

Hysteresis data

width

S1 Judgement display,

S1 Contact output

(4)

When the operation of “contact ON less than or equal to set value” is selected at S4, and also

effective direction for hysteresis is set as “OFF delay”.

OFF

Time

Display

S1 Set value

Hysteresis data

width

Hysteresis time width

S1 Judgement display,

S1 Contact output
