9−2. BCD output
Warning ● When power ON the instrument with the external HOLD signal
shorted, BCD output will be as follows:
1
Even when the Display is targeted for HOLD with the FUNC−50,
BCD output outputs “000000” if the target for BCD output is set
as Display.
2
When an option is assumed to be the target for HOLD with the
FUNC−50, BCD output outputs “000000”.
3
Other than the case above ① and ②, present load value will
output after “000000” has outputted.
● When the CHECK switch is applied, pay attention to the following
points.
1
By ON operation of CHECK, the instrument isn’t in Measurement
mode any more(RUN display puts off. RUN output is open.),
however, BCD option will continue to output.
2
By ON operation of CHECK, “OL” error display might be shown
(BCD output is OVR).
9−2−1.
Related functions
FUNC−20 Selection on the target for BCD output.
Display, Net Weight,
Gross Weight, External Selection.
FUNC−21 Selection on output logic for BCD data. Negative Logic, Positive Logic
FUNC−22 Selection on output logic for BCD polarity. Negative Logic, Positive Logic
FUNC−23 Selection on output logic for BCD flag. Negative Logic, Positive Logic
FUNC−25 Selection on output logic for P.C. Negative Logic, Positive Logic
FUNC−26 Selection on changeover for P.C. width. Approx. 25 ms, approx. 125 ms.
