Procedure

Press the key.

The load display will show “A−END”.

By pressing the key again, VADJST mode is

over and returns to the Measurement mode and

the load will be indicated.

At the same time, the result from fine adjustment

on analog output will be renewed.

In this procedure, possible value to make

adjustment is 10 % of output value for both

zero and span.

However, when the adjustment is made in

the procedure described in the paragraph

9−1−9, take care not to exceed 10 % of

total adjustment value.(Added adjusted

value in the paragraph 9−1−9.)

±±

±1.6 mA

Option No.

P23

Adjustment

Value

P07

±±

±0.1 V

±±

±0.5 V

±±

±0.4 V±

±±

±1.0 V

P24

P25 P26
