45
7−2−4.
Operation of comparator SO
The comparator SO in the instrument can select one operation among eight(8) from “000000”
to “000007”. These selections can be made in Function mode(Related Function FUNC−13).
As for default, “000000” is selected.
Warning ● Depending on operational selection for comparator, ON/OFF
condition for SO contact output may differ. If wrong mode is selected,
ON/OFF condition for SO contact output become inadequate and it
may cause an unexpected accident due to malfunction on peripheral
instruments, so care should be taken fully.
As for example, the operation of SO judgement display and SO contact output is shown at the
time of whichever setting is selected among “000000” to “000007” with Function FUNC−13.
Setting
FUNC−13
Operation
000000 Always OFF
000001 ON when both of S1 and S2 contact output are OFF.
000002 ON when both of S1 and S3 contact output are OFF.
000003 ON when both of S1 and S4 contact output are OFF.
000004 ON when both of S2 and S3 contact output are OFF.
000005 ON when both of S2 and S4 contact output are OFF.
000006 ON when both of S3 and S4 contact output are OFF.
000007 ON when (Gross weight)≧(Max. display value)
In the next, as for the sample, the operation at SO judgement display and SO contact output
selected “000001” with FUNC−13 among “000000” to “000006” will be shown as below.
Same operation will be performed when “000002”, “000003”, “000004”, “000005” or “000006”
is selected with FUNC−13.
