1−1. Installation

● When installing the instrument, install as referring to the following

figures and secure the space around the instrument.

Each dimension of the instrument and required dimensions for the environmental spaces are as

follows:

< Dimensions for installation >

Side

Panel cut size

Front

Unit : mm

Rear

192

15 160 (20.3)

187

＋

＋＋

＋1

186

＋

(46)
